$399.99 USD

The Aegis Battery 60V 15Ah Li-ion Battery*  is a state of the art rechargeable battery pack made with 18650 cells designed for 60V devices. It is perfect for e-scooters, e-bikes, solar applications, robots, and other applications that require a higher-energy density battery. The battery comes with integrated Anderson Power Pole connectors making it a perfect drop in solution for your applications. The Aegis battery has a built in battery management system (BMS) that keeps the battery running at peak performance and protects the cells for thousands of cycles, including over-charge, over-discharge, over-current, and short-circuit protection.

Clearance Serial #ABLP1908186015002

If this connection does not meet your needs, you may also view alternative adapters here.

For out of stock kits, we may be able to provide another compatible charger. Please contact us and we can check for you.

ABL-060015P Product Manual

For more info & usage notes for our lithium batteries, please click here.

 Specifications

Battery Type PVC Pack
Battery Chemistry Lithium-Ion
Cell Type/Assembly Method Cylindrical cells/welded
Voltage (V) 60V
Capacity (Ah) 15Ah
Energy Stored (Wh) 900 Watt-Hours
Weight 12.02 lbs
Dimension (L x W x H) 8.25" x 5.25" x 5.8"
Cycle Life 1000+ cycles
Normal Charge Current 3.0 Amps
Nominal Continuous Discharge Current 7.5 Amps
Maximum Continuous Discharge Current 15.0 Amps
Maximum Peak Discharge Current 30.0 Amps
Charge Temperature 0°C to 45°C
Discharge Temperature -20°C to 60°C
Operating Humidity 60±20%R.H
Storage Humidity 60±20%R.H
Automatic Battery Protection Module/System Low Voltage Disconnect,
Over Voltage Disconnect,
Short Circuit Protection,
Reverse Polarity Protection,
Cell Balancing



Compatible AC-to-DC Charger Specifications:

Input Voltage: AC110V-240V, 50/60HZ
Output Voltage: 71.4VDC
Current: 3A
Connector: IEC C14 (Female)
Model Number: CRG-06003P

NMC Advantage
- Advanced NMC (Nickle Manganese Cobalt Oxide) Li-ion Chemistry superior to traditional Li-ion Batteries
- All-Aspect Solution with best overall balance of features
- Highest Specific Energy (150-220Wh/kg)
- Ideally Suited for EV and High Energy Consumption Applications
- Excellent Lifespan (1000-2000 Cycles Average)

Intelligent Technology
- Battery Management System (BMS) Board as Standard
- Every Battery has bespoke board matching its performance parameters
- Comprehensively balances charging and discharging
- Internal balancing circuitry and charger circuitry inside BMS
- Comprehensive protections against over-charge, over-discharge, over-voltage, over-current, short circuits, reverse polarity, thermal protection
- Dramatically extends service life

Comprehensive Improvements
- Achieve full depth discharge of 100% Label Capacity
- “True Lithium Capacity” guarantees capacity of purchase is capacity delivered
- Reliable, repeatable full depth cycling without system life cycle degradation
- NMC Systems can be fully discharged safely without impact on system performance
- Multiple times usable capacity of Lead Acid


Policy
Warranty: 30 Days
Shipping: Standard within 2 business days
