36V 20A LiFePo4 LFP Lithium Battery Charger


Out of stock

Regular price $169.99
The Aegis Battery 36V 20A LFP Charger is a state of the art energy transfer device made and designed for Li-ion battery packs. This charger provides the required constant current, followed by constant voltage (CC/CV) charge profile for charging Li-ion batteries. This charger includes an LED display that changes from...

The Aegis Battery 36V 20A LFP Charger is a state of the art energy transfer device made and designed for Li-ion battery packs. This charger provides the required constant current, followed by constant voltage (CC/CV) charge profile for charging Li-ion batteries. This charger includes an LED display that changes from red to green once the battery has reached full capacity.

Specifications

Model: CRF-03620M
Product Type: Metal Case
Battery Chemistry: Lithium Iron Phosphate - LiFePo4
Charging Connector: Alligator Clips
Input:
AC110-24V, 50/60HZ
Output:
43.8V 20A (CC/CV Charge Profile for 36V Li-ion Batteries)
Capacity (Ah) of the charging battery: 75Ah or higher (recommended)
Weight: 1.8 kg (4.0 lb)
Dimension (L x W x H): 8.0 in. x 4.7 in. x 3.7 in.
Normal Charge Current: 20.0 Amps
Charge Temperature: 0°C to 45°C
Storage Humidity: 60±25%R.H
Battery Protection Module*

Low Voltage Disconnect,
Over Voltage Disconnect,
Short Circuit Protection,
Reverse Polarity Protection,
Cell Balancing

  *Protections are integrated into Battery Pack BMS as standard



Policy

Warranty: 2 years standard Lithium-Ion Battery Warranty

Repair or Replace: first 2 years

Returns/exchange: 30 days

Cancellation: Within 24 Hours ⟶ No charge

Shipping: Standard within 2 business days
